Engineering Vehicles
Engineering Vehicles
Core Product Features
High-safety Structural Design
The cab uses a fully enclosed frame structure; critical areas such as A-pillars, B-pillars, and roof cross-members are reinforced to comply with ROPS (Roll-Over Protective Structure) and FOPS (Falling Object Protective Structure) standards, effectively protecting the operator in complex working conditions.
Panoramic Visibility Optimization
A large windshield, well-arranged side and rear windows, and a low instrument panel minimize blind spots, improving operation precision and safety.
Ergonomic Interior Pre-reservation
The interior is spacious. Seat mounting positions, joystick brackets, and instrument panel interfaces are all pre-reserved, allowing later installation of comfort features such as air conditioning, audio, and monitoring cameras.
Modular Quick-detach Design
Doors, top cover, and floor panels use standardized bolted connections, supporting fast disassembly and replacement — reducing maintenance cost and improving equipment availability.
Technical Specifications
| Applicable Model | 20 – 35 ton class hydraulic excavator / small loader |
|---|---|
| Body Material | High-strength cold-rolled steel + ABS engineering plastic covers |
| Painting Process | Cathodic e-coat primer + top coat spraying |
| Main Dimensions | Approx. 1.8 m L × 1.2 m W × 2.0 m H |
| Net Weight | Approx. 350 kg – 450 kg (excl. interior, glass, electricals) |
| Safety Certification | ISO 3471 (ROPS) & ISO 3449 (FOPS) compliant |
| Compatible Brands | Compatible with SANY, XCMG, LiuGong, Caterpillar and other mainstream chassis |
Recommended Application Scenarios
- Mining: Sturdy body structure resists rock impact; wide field of view ensures safety during blasting and loading operations.
- Municipal Construction: Compact size fits urban narrow-space work; low-noise design reduces impact on nearby residents.
- Agriculture & Water Conservancy: Excellent dust sealing, suitable for dusty environments. Optional liftable cab provides better high-altitude operation visibility.
- Port Logistics: Corrosion-resistant coating adapts to humid, salt-spray environments; modular design enables quick maintenance.
